SV226 Telescope Filter Drawer - 1.25" & 2" Astronomy Filter Combination for Astrophotography

SKU: W9184A-

US$ 49.99

Double pair of magnets; SV226 photographic filters drawer compared with traditional screw rotation; magnet has stronger adsorption force; which is convenient for you to install and use
Two filter holders; compatible with 1.25-inch and 2-inch filters; plug and play; reducing repeated installations in dark environments
Locking function; lock screw can adjust the tension to eliminate the gap; solve the light leaking issue under long exposure; which is a double insurance for you
M42-M48 adapter; camera side thread is male; filter mounts thread is female; you can use the adapter to coonect cameras of different specifications
CNC integrated molding; more precise production process; strong and sturdy; you can use filter drawer with confidence
Filter drawer thickness; the thickness is related to back focal length; back intercept affects the quality of imaging; it limits the use of accessories and optical path length
Use with telescope; connect the telescope to the focal reducer and drawer filter; then connect the adapter to the camera

2 inch Holder

Drawer + 2inch Holder

Filter Set + Drawer

In Stock

Add to Wishlist

Filter Drawer + UV IR Cut Filters 1.25inch Filter Drawer + UV IR Cut Filters 2inch Filter Drawer + UHC Filter 1.25inch Filter Drawer + UHC Filter 2inch Filter Drawer + CLS Filters 1.25inch Filter Drawer + CLS Filters 2inch Filter Drawer + SV220 Dual-Band Filters 1.25inch Filter Drawer + SV220 Dual-Band Filters 2inch Filter Drawer+Color Correction Filter 2inch

Product Details
Product Reviews
SPEC
feature

SV226 Filter Drawer Integrated Molding Anti-Light-Leaking Design for 1.25" &2" Filter Mounted

Double Pair of Magnets

Compared with traditional screw rotation; magnet has stronger adsorption force; which is convenient for you to install and use.

Two Filter Holders

Standard 1.25" and 2" filter holder; plug and play, easy to use; reducing repeated disassembly and installation steps in a dark environment.

Compatible With 1.25”& 2” Filter Installation

Existing 1.25" and 2" filters can also be used; for beginners of photography; save the budget for changing filter sizes.

CNC Integrated Molding

The advanced processing can assure the quality; provide more accurate; consistent results; you can use it with confidence.

Filter Drawer Thickness 21mm

The thickness is related to back focal length; back intercept affects the quality of imaging; it limits the use of accessories and optical path length. Designed with the lock screw on the side of the filter drawer; the locking function is helpful on adjusting the tension to eliminate the gap; which is a double insurance for you.

The Parameters Of SV226 Filter Drawer

Use With Telescope

Connect the telescope to the focal reducer and drawer filter; then connect the adapter to the camera. This SV226 filter drawer can use with SV550/SV503 OTA and F9198F/F9198K astronomy cameras.

M42-M48 Adapter

Camera side thread is male; filter mounts thread is female; The filter drawer comes with the M42-M48 adapter to resolve the thread compatibility issue. The interface can help you use the adapter to connect cameras of different specifications.

Plastic Dustproof Storage Box

The packaging is equipped with a plastic storage box to ensure that accessories around the filter drawer can be stored.

5 reviews

Write a review

Name

Rating

Review Title

Body of Review (1500)

Good!!!

Daniel Paulino on Jun 14,2024

amazing quality and price

Nice inexpensive filter drawer

Cc on Jun 06,2024

Everything is very solid and screws together very easily, and I like that it came with an extra drawer and a 2"-1.25" adapter. Sometimes I forget which way the drawer goes and try to put it in backwards which of course doesn't work, but that's about my only complaint and that's more user error than their fault lol.

Excellent Quality and fast delivery on the filter drawer.

Mark Powell on May 25,2024

I was very surprised with the high quality of the filter drawer. It came with everything that I needed to add into my imaging train and I can use 1.25 or 2 inch filters. What really surprised me was how fast the delivery was coming from China. Normally I don't expect to see a package from China for a few weeks, but they delivered it in six days ! Well done Svbony ! It was the right item at the right price and shipping was super fast.... I'm a very happy customer !

SV226 Telescope Filter Drawer for 1.25inch & 2inch Filter

Christian Totth on May 25,2024

I 'm quite happy with it. It's versatile, i.e. one can rapidly switch between filters, be it 2" or 1.25" ones, even in the dark. It closes tight due to the magnetic locking system, so no light leaks to see. I wished it would have been sold wih more than only two filter holders per unit, or to be able to buy them separately. Yet, as it is, excellent for the price!

filter drawer for mono and color ccd

Giovanni Leoni on Dec 14,2023

arrived today! it's a master piece cnc adapter complete with all the adaptors you need to connect to a ccd and a telescope. love it!

Specifications

Brand	SVBONY
Model	SV226
Product Name	Filter Drawer
Thickness	21mm
Support Filter size	1.25" &2"
Material	Aluminum
Camera side thread	M42 x0.75 (male)
Filter mounts thread	M48x0.75/M28.5x0.6 (female)
Telescope side thread	M48x0.75 (female)
Net Weight	400g
Diameters	130x120x100mm

Features
1.2-in-1 design, can use offilter1.25" & 2" specifications on the market
2.With strong the ability of double strong magnetic adsorption, it is more convenient and much easier to install or pull out the filter.
3.Advanced CNC integrated molding processing, quality assurance
4.Lock screw on the side of it. The locking function is helpful on adjusting the tension to eliminate the gap, which is a double insurance for users.
5.The filter drawer comes with the M42-M48 adapter To resolve the thread compatibility issue.
Package Includes
Drawer Frame x 1PCS
2. 2" Filter Slider x2PCS
3. 2"-1.25" Filter Adapter x1PCS
4. M42F-M48M Adapter x 1PCS
5. Plastic Case x 1PCS
