The popular SV503 series includes SV503 102ED refractor OTA, SV193 0.8x field flattener & focal reducer, SV165 mini guide scope, the side dovetail slot, the SV226 filter drawer and SV211 red handle bar. This bundle set will provide the best optical quality, whether you use it for Deep-Sky Object or Planets, visual or photography.
| Product Name | SV503 70F6 ED Astronomy Telescope | SV503 80F7 ED Astronomy Telescope | SV503 102F7 ED Astronomy Telescope |
| Type | Refractor | Refractor | Refractor |
| ED Glass | S-FPL51 | S-FPL51 | S-FPL51 |
| Coating | SMC | SMC | SMC |
| Aperture | 70mm / 2.75-Inch | 80mm /3-Inch | 102mm / 4.01-Inch |
| Focal length | 420mm | 560mm | 714mm |
| Focal Ratio | f/6 | f/7 | f/7 |
| Type of Focuser | RAP (Rack and Pinion) | RAP (Rack and Pinion) | RAP (Rack and Pinion) |
| Gear Reduction | 1:10 Fine movement | 1:10 Fine movement | 1:10 Fine movement |
| Resolving capacity | 1.97" | 1.5" | 1.17" |
| Limit value | 11.3 | 11.6 | 12.1 |
| Light gathering capacity | 100x | 130.6x | 212x |
| Max. Useful magnification | 140x | 160x | 204x |
| Tube weight | 3.35kg | 3.95kg | 5.5kg |
| Tube outer diameter | 88mm | 121mm | |
| Tube material | Aluminum | Aluminum | Aluminum |
| Back Focus Length | 90mm | 90mm | 101.9mm |
| OTA Length | 318mm | 465mm | 630mm |
| Dovetail & Ring | Yes | Yes | Yes |
| Dovetail Length | 150mm | 137mm | 200mm |
| Model | SV193 | ||||
| SKU | W9152A | W9152B | W9152D | ||
| Back focus | 55mm | ||||
| Barrel size | M54x0.75 | 2-inch | 2-inch | ||
| Threads Standard | M48*0.75 | M48*0.75 | M48*0.75 | ||
| Lens Structure | 3-Elements/3Groups | 3-Elements/2Groups | 3-Elements/2Groups | ||
| Lens Coating | FMC | FMC | FMC | ||
| Blackened Lens Edges | Yes | Yes | Yes | ||
| Net Weight | 273g / 9.63oz / 0.6lb | 164g / 5.78oz / 0.36lb | 177g / 6.24oz / 0.39lb | ||
| Model | Svbony SV165 |
| Aperture | 30mm |
| Focal length | 120mm |
| Focal Ratio | F4 |
| Hoop and Mount | Yes |
| Back Focus Length | 45mm |
| Mount | UNC 1/4-20 |
| Material | Aluminum |
| Surface technology | Sandblasting oxidation |
| Model | W2370A |
| Length | along the 34mm |
| Width of internal slot | 4.2mm |
| Horizontal length of internal slot | 36.5mm |
| Vertical length of internal slot | 36.5mm |
| Can be fixed | M3-M4 screw |
| Color | Black |
| Weight | 41g |
| L*W*H | 45*40*25mm |
1. The popular SV503 series refractor will provide the best optical quality, whatever you use it for Deep-Sky Object or Planets, visual or photography;
2. The compatible SV193 reducer will increase the field of view and improve the image flatness， which is essential for deep-sky photography;
3. The SV165 guide scope is very mini and easy to use, widely used in different Astro-observations;
4. The side dovetail slot provides you with an easy way to install the finder;
5. This combination will provide more choices among different ways to use your SV503 telescope.
